View Manager provides the ability to visualize view definition and view management. It is very convenient to use for view management. Skilled use will greatly improve design efficiency.
Use the View - Named View in the Haochen CAD menu to open the View Manager, or type v on the command line.
Select "New" in the dialog box to name multiple views for the current working drawing according to different viewing areas or viewing angles, so that the view can be called to view the drawing.
Enter the view name. The "Current Display" option means to save the current display area as a view, or select the "Define Window" option to specify a view window by the user.
As an example, here we have created three new views, setting area A and area B to display two different plan view areas, and setting the isometric view to show the observation results of the isometric view. Select a view and click on the "Set as current" option to invoke the view.
All drawings are shown
The following three views are called separately, and the results are as follows
Area A
Area B
Isometric view
